光纤手持式激光焊接机简介
光纤手持式激光焊接机,用手持式焊接枪替代以前固定光路,手拿焊接,灵活方便,焊接距离更长,克服工作台空间的局限性,工件尺寸不统一时无法自动焊接的情况下使用。主要针对大型工件、固定位置如内直角、外直角、平面焊缝焊接、焊接时热影响区域小,变形小、而且焊接深度大,焊接牢固。是远距离焊接大工件的较为灵活的全新的焊接工艺。
optical fiber hand-held laser welding machine uses a hand-held welding gun instead of the fixed optical path. It is flexible and convenient to handle welding, and has a longer welding distance. It overcomes the limitation of worktable space and can not be used automatically when the workpiece size is not uniform. Mainly for large workpieces, fixed position such as inner right angle, outer right angle, plane weld welding, welding heat affected area is small, deformation is small, and welding depth is large, welding is firm. It is a new flexible welding process for long distance welding of large workpiece.
光纤手持式激光焊接机特点Characteristic
1、手持式焊接枪替代以前固定光路,更灵活方便,实现远距离激光焊接,克服工作台行程空间的局限性;
2、手持焊接头轻便灵活,操方便简易,满足多种角度、多种位置的焊接;
3、手持式焊头可配备5米/10米进口光纤,灵活方便可以实现户外焊接;
4、采用红外线定位,用于焊接头位置校对和焊接时的位置验证,焊接位置更准确,确保焊缝更美观;
1. The hand-held welding gun replaces the fixed optical path before, which is more flexible and convenient, realizes long-distance laser welding and overcomes the limitation of worktable travel space.
2. Hand-held welding joints are portable and flexible, easy to operate, and can satisfy welding of various angles and positions.
3. The hand-held welding head can be equipped with imported optical fibers of 5 meters/10 meters, which can realize outdoor welding flexibly and conveniently.
4. Infrared positioning is used to correct the position of welding joint and verify the position during welding. The welding position is more accurate and the weld is more beautiful.
光纤手持式激光焊接机应用:Application:
比较大尺寸及不规则工件焊接,例如:钣金、机箱、水箱、厨卫、洗手盆类钣金五金激光密封焊接;各类五金灯式激光焊接;门窗框架类激光焊接;广告牌、广告字激光焊接等等
Compare large size and irregular workpiece welding, such as: sheet metal, chassis, water tank, kitchen and toilet, washbasin sheet metal metal laser sealing welding; all kinds of metal lamp laser welding; door and window frame laser welding; billboard, advertising laser welding and so on.
光纤手持式激光焊接机技术参数Technical parameter
激光波长 | Laser Wavelength | 1070-1080nm |
激光功率 | laser power | 800W/1000W/1500W |
激光器输出稳定性 | Laser output stability | ±2% |
激光器重量 | Laser weight | 40Kg |
光纤直径 | Optical Fiber Diameter | 100um |
光纤长度 | Fiber length | 5米、10米 |
光斑可达 | Facula accessibility | φ0.2mm |
泵浦源 | Pump source | 半导体Semiconductor |
光束质量 | Beam quality | ≤1.1 |
瞄准定位 | Aiming and positioning | 红光+内、外角自动焊接装置Red Light + Inner and Outer AngleAutomatic Welding Device |
激光器主机耗电功率 | Power consumption of laser host | 4KW/6KW |
电力需求 | Electricity demand | 220V或380V |
冷却方式 | Cooling mode | 水冷、去离子水Water Cooling and Deionized Water |
主机尺寸 | Host Size | 600*800*1400mm |
